ACE AX-130 Backhoe Loader
Key Specifications
-
Capacity-
EngineN/A
CoolingN/A
N0. of Cylinder60-1350 mm
Cutting Height₹ 17 Lakh
PriceDESCRIPTION ACE AX-130 Backhoe Loader
ACE is a very popular name in the heavy construction equipment segment. ACE AX-130 is designed with segment best specification, which helps in providing better work efficiency. The Backhoe Loader model from ACE Construction equipment is one the best Construction machines in heavy loading work. This Backhoe Loader also comes with an operating weight of 7500 Kg, which increases your output. Here you quickly get the ACE AX-130 price in India with all its features.
ACE AX-130 Backhoe Loader Engine
ACE AX-130 comes with an engine which generates 76 HP and maximum torque of 300 NM. In addition, this engine gives a new dimension to work output to this ACE AX-130.
ACE AX-130 Backhoe Loader Weights
The ACE AX-130 comes with an operating weight of 7500 Kg. This operating weight of ACE and AX-130 increases the effectiveness in the heavy construction works.
ACE AX-130 Backhoe Loader Price in India
ACE AX-130 Backhoe Loader price starts from ₹ 17 Lakh and goes up to ₹ 24 Lakh in India. This price of ACE AX-130 Backhoe Loader contains all the specifications of the heavy duty equipment. You can comfortably buy ACE AX-130 with the help of Infra Junction. In addition, we will provide you with every minor information about the ACE AX-130. At Infra Junction, you can easily get the on-road price of ACE AX-130 Backhoe Loader with all government taxation amounts.
Why Infra Junction is Best For ACE AX-130 Backhoe Loader
We provide you with a platform where you can compare this AX-130 with other products of the Backhoe Loader category. ACE Backhoe Loader provides high quality work with its implemented components. Along with all the details of AX-130, you can also get an updated price of ACE AX-130.
Specifications
-
CompliantBS-III
-
ModelKIRLOSKAR 4R1040T
-
Air Intake TypeTurbocharged Water Cooled
-
Gross Power76 HP
-
Maximum Torque300 NM
-
Dump Height2780 mm
-
Load Over Height3250 mm
-
Hinge Pin Height3460 mm
-
Reach At Ground1950 mm
-
Max Reach At Full Height1530 mm
-
Rollback At Ground40 Degree
-
Dump Angle42 °
-
Bucket Capacity Std1 Cum
-
Maxd Dig Depth4700 mm
-
Reach at full height to slew center2810 mm
-
Max Working Height5290 mm
-
Max Load Over Height3620 mm
-
Bucket Rotation185 Degree
-
Max. lift capacity1490 Kg
-
Backhoe Bucket capacity0.24 Cum
-
Max Operating Weight7500 Kg
-
Width Over Bucket2380 MM
-
Track Width Rear1720 MM
-
Track Width Front1840 MM
-
Wheelbase2220 mm
-
Minimum Ground Clearance260 mm
-
Height to top of cabin2900 mm
-
Pump Flow118 IPM
-
System Relief Pressure210 Bar
-
Engine Oil11 Ltr
-
Rear Axle3 Ltr.
-
transmission Oil Capacitysystem17 Ltr.
-
Fuel Tank160 Ltr
-
CoolantWater Cooled
-
Hydraulic oil - System135 Ltr
-
Transmission make and modelSynchro-shuttle transmission with torque conventer
-
RearRigid axle with CARRARO planetary drive
-
FrontDrive & Steer Axle, centrally pivoted
-
TypeHydrostatic steering for reliability and better control
-
Brakes serviceHydraulically Actuated Disc Brakes
-
Brakes ParkingMechanically Actuated Disc Brakes For Parking
-
Standard tyre front9.00 x 16 – 16 PR
-
standard tyre rear16.90 - 28 - 12 PR
-
Battery12 V
FAQ'S
A. The ACE AX-130 price in India starts from ₹ 17 Lakh and it goes up to ₹ 24 Lakh.
A. The operating weight of ACE AX-130 is 7500 Kg.
A. The engine power of ACE AX-130 Backhoe Loader is 76 HP.
A. The ACE AX-130 comes with the KIRLOSKAR 4R1040T type of engine.
